•  UFT (Ultra Fine Touch) Technology
•  myViewBoard™ digital whiteboard software
•  ViewBoard® Cast 4-way split screen content sharing software
•  SmartPort™ shared front USB ports for internal & external PCs
•  2.0 Stereo sound

UFT Technology

UFT Technology enables precision writing with a 2.5mm diameter pen tip.

Dual-Pen

Automatically detect pen diameter (8mm & 2.5mm) and write simultaneously with different colours and thicknesses.

Full Native Performance on embedded OS

Built-in myViewBoard™ digital whiteboarding software to collaborate on the go.

4-way Split Screen

4-way split screen content sharing with built-in ViewBoard® Cast software.

Shared USB Ports

SmartPort™ shared front USB ports for internal & external PCs.

Stereo Sound

2.0 Stereo sound

Faster Internet

GigaLAN provides a faster, more powerful internet connection.

Remote Control

Built-in RS232 port and vController software for remote control.

Slot-in PC

Slot-in PC with Intel 8th-gen CPU (Optional).

Web Camera

Top-mounted 1080p web camera (Optional).

I/O Ports

1. USB 2.0 X 2
2. HDMI OUT
3. USB 3.0 X 3
4. USB Touch Port
5. HDMI In X 3
6. USB Touch Port
7. VESA^® WALL Mount 800×600 mm
8. AC IN
9. VGA
10. AUDIO IN
11. SPDIF Out
12. RS232
13. AUDIO OUT
14. LAN
15. USB 2.0

SPECIFICATIONS

• DISPLAY
  Panel Size: 98″
  Type/Tech: TFT LCD Module with DLED Backlight.
  Display Area (mm): 2171.85(H) x 1232.35(V) (97.52”diagonal)
  Aspect Ratio: 16:9
  Native Resolution: UHD 3840×2160(Pixels)
  Colours: 1.07B colours (10bit)
  Brightness: 500 nits (typ.)
  Contrast Ratio: 1200:1 Typ. , 5000:1 Max.
  Response Time: 6ms
  Viewing Angles: H = 178, V = 178 typ.
  Backlight Life: 30,000 Hours (Min)
  Surface Treatment: Anti-Glare
  Orientation: Landscape
• PLATFORM
  Processor: ARM Cortex A73*2(1.5GHz)+A53*2(1.2GHz)
  RAM: 3GB DDR4
  Storage: 16GB
• TOUCH
  Type/ Tech: IR Recognition
  Touch Resolution: 32767 x 32767
  Touch Point: 20 points touch, 10 points writing

• INPUT
  HDMI: 2.0 x3 (3840×2160 @60Hz)
  RGB / VGA: x1
  Audio: x1 (PC audio in)
  RS232: x1
  OPS: x1 PC Slot
• OUTPUT
  HDMI: x1
  Audio: x1 (Earphone out)
  SPDIF: 1(optical)
  RS232: x1
• LAN
  RJ45: x1
• USB
  Type A: USB 2.0 x3
  USB 3.0 x3
  Type B: x2, for touch
• SPEAKERS
  SPEAKERS: 12Wx2
• CAMERA PLATE ON TOP FOR SCREW-IN WEBCAM INSTALLATION
  Camera plate on top for screw-in webcam installation: Yes
• COMPATIBILITY
  HDMI: 3840×2160
• USB SUPPORTED FILE FORMAT
  USB SUPPORTED FILE FORMAT: Picture –
  BMP, JPEG, PNG,GIF

  Video –
  Codec: H.263, H.264, MJPEG, MPEG2, MPEG4, RV30/40, VP6, Xvid-ASP
  Container: 3GP, ASF, ASX, AVI, FLV, M4V, MKV, MOV, MP4, MPG, MPEG, RMVB, TS
  H.265

  Audio –
  Codec: AAC, ALAC, FLAC, MPEG 3, Vorbis, WAV, WMA
  Container: AAC, APC, FLAC, M4A, MP3, OGG, WAV, WMA

• BUNDLE SOFTWARE
  Basic Annotation Software: myViewBoard for android
  Pro Annotation Software: myViewBoard for windows (Embedded in Windows Slot-in PC)
  Wireless Presentation with Touch Feedback: Viewboard Cast: ViewBoard Cast
• SPECIAL FEATURES
  All-in-one USB port (combine Windows/Android USB port; no need to distinguish them anymore): Front “SmartPort USB” to all channels.
  Simple LAN sharing between IFP and slot-in device: Yes
• POWER
  Voltage: 100-240VAC +/- 10% Wide Range
  Consumption: 171 (Typ.)
  < 0.5 W (“Off”)
• ERGONOMICS
  Wall Mount (VESA® ): 800 x 600
• OPERATING CONDITIONS
  Temperature (º C): 0°C to 40°C
  Humidity: 10% ~ 90% RH non-condensing
• DIMENSIONS (W X H X D)
  Physical (inch / mm): 88.4 x 52.1 x 3.6 in / 2245 x 1323 x 91 mm
  Packaging (inch / mm): 97.8 x 58.8 x 14.8 in / 2483 x 1493 x 376 mm
• WEIGHT
  Net (lb / kg): 223.77 lb / 101.5 kg
  Gross (lb / kg): 306 lb / 138.8 kg
• REGULATIONS
  REGULATIONS: FCC, cTUVus
• ENERGY STAR VERSION
  Energy Star version: ES8.0
• EEI RATING
  EEI rating: A++
• PACKAGE CONTENTS
  PACKAGE CONTENTS: 1. Power cable(3 meters) x 4 2. Remote control 3. USB cable(3 meters) 4. Touching pen x 2 5. Quick Start Guide 6. RS232 adapter 7. Clamp x 5 8. Plate 9. Screw x 8 10. HDMI cable
• COMPATIBLE SLOT-IN PC
  Compatible Slot-in PC: VPC14-WP series
  VPC10-WP series
  VPC15-WP series
  VPC16-WP series
  VPC17-WP series
