Ahuja SSW-16: 16-Channel Manual Zone Selector

Ahuja SSW-16: Manual 16-Channel Zone Selector for Flexible 100V Audio Distribution

In expansive public address (PA) systems found in large commercial complexes, educational institutions, factories, or hotels, the ability to direct audio announcements or background music to specific areas is crucial for effective communication and efficient operations. Broadcaster-wide messages can often be disruptive or unnecessary. The Ahuja SSW-16 16-Channel Manual Zone Selector provides a straightforward yet powerful solution for managing complex multi-zone audio distribution. This compact and reliable unit allows you to manually switch a 100V audio signal to one, multiple, or all of up to 16 distinct zones, putting precise control right at your fingertips.

Direct Control Over 16 Audio Zones

The SSW-16 empowers you with granular control over your audio distribution, making it ideal for large-scale installations.

• Key Benefits:

  • Individual Zone Switching: Manually switch a 100V audio signal to one or more of up to 16 individual zones, ensuring your message reaches only the intended areas.
  • 16 x 100V Outputs: Provides dedicated 100V outputs for each of the 16 zones, ensuring compatibility and optimal signal transfer with your existing 100V line speaker systems.
  • 1 x 100V Input: Accepts a standard 100V audio input from your PA amplifier or mixer, simplifying integration.
  • Benefit to You: Gain unparalleled flexibility in directing audio announcements or background music, enhancing communication efficiency and minimizing disruption in large, multi-area environments.

Universal Broadcasting with All-Call & Clear Status Indication

Beyond individual zone control, the SSW-16 ensures you can address your entire facility when needed, with clear visual feedback.

• Built-in Relay for ALL CALL: Features a dedicated “ALL CALL” function activated via a built-in relay, allowing for instantaneous broadcasting to all 16 zones with a single switch.
• LED Indication of Selected Zones: Each of the 16 zone selector switches is accompanied by an LED indicator, providing clear visual confirmation of which zones are currently active.
• Dedicated Switches: Simple and intuitive operation with individual zone selector switches, an ALL CALL switch, and a Power ON/OFF switch.
• Benefit to You: Handle both targeted and universal announcements efficiently, with immediate visual confirmation of your active zones, ensuring reliable operation.

Robust Design and Versatile Power Options for Reliability

The Ahuja SSW-16 is built for continuous operation in demanding professional environments, offering flexible power solutions.

• Standard AC & DC Power Supply: Can be powered by standard AC 220-240V, 50/60Hz mains, or by DC 24V (from 2 x 12V Car Battery) for backup power or specific installation requirements.
• Rack-Mountable Design: Its compact dimensions (W483 × H53 × D180 mm) ensure it fits perfectly into standard 19-inch audio equipment racks, promoting a neat and organized professional setup.
• Compact and Lightweight (2.70kg): Despite its robust capabilities, it’s easy to handle and install.
• Benefit to You: Enjoy peace of mind with continuous operation due to flexible power options and seamlessly integrate this essential control unit into your existing audio rack infrastructure.

Simplifying Complex Audio Distribution

The SSW-16 is a vital component for:

• Efficient Zone Management: Reduces clutter and complexity compared to using multiple individual switches for each zone.
• Cost-Effective Solution: Provides a centralized, manual zoning solution without the need for more complex and expensive digital matrices in certain applications.
• Reliable Performance: Manual switching offers a dependable method of audio distribution, ideal for installations where simplicity and robustness are prioritized.
• Integration with Existing 100V Systems: Designed specifically for 100V line audio systems, making it a perfect fit for most commercial PA infrastructures.

Ideal Applications:

The Ahuja SSW-16 16-Channel Manual Zone Selector is highly suitable for:

• Large Office Buildings: Paging specific floors or departments.
• Shopping Malls: Directing announcements to particular sections or stores.
• Manufacturing Plants & Warehouses: Broadcasting safety messages or instructions to specific work areas.
• Hotels & Resorts: Managing announcements to different wings, lobbies, or conference areas.
• Educational Campuses: Directing announcements to specific buildings or classrooms.
• Sports Complexes & Stadiums: Managing audio to different seating sections or facilities.

Take precise control of your multi-zone audio system!

The Ahuja SSW-16 16-Channel Manual Zone Selector is an indispensable tool for anyone managing a multi-zone 100V public address system. Its robust design, intuitive manual control over 16 individual zones, and efficient all-call capability provide unparalleled flexibility and reliability in audio distribution. Streamline your communication, ensure messages reach their intended audience, and maintain optimal control over your PA system with the SSW-16.

Order Ahuja SSW-16 today and experience streamlined communication! Contact us for more information, customized AV/conference solutions.
