CMX PA-6000WP – Remote Control Panel
Professional In-Wall Audio Matrix Remote Control Wall Panel with Built-In Bluetooth Receiver, Digital Source Selection, Visualized Volume & Channel Display, CAT6 Connectivity Up to 999m & Direct Bus Power for CMX PA-6000 Series Matrix Amplifiers
The CMX PA-6000WP is an architectural in-wall audio matrix remote control wall panel engineered specifically for the CMX PA-6000 series matrix mixer amplifiers (including models PA-6030MX, PA-6060MX, PA-6120MX, PA-6030MW, PA-6060MW, and PA-6120MW). Built to provide decentralized zone management across multi-room commercial sound installations, the PA-6000WP enables occupants in VIP dining rooms, executive boardrooms, hotel suites, or fitness studios to select central background music sources and fine-tune room loudness without accessing the central equipment rack. Each unit features an integrated Bluetooth receiver for streaming smartphone audio locally within that specific room, alongside dedicated local microphone and auxiliary line inputs. Operating over standard straight CAT6 network cabling up to an exceptional 999 meters and powered directly by the host amplifier’s 24V DC bus, the PA-6000WP combines clean architectural aesthetics with effortless zone control.
Ideal For
Core Engineering Features
Decentralized 6-Zone Matrix Source & Volume Selection
Enables occupants in any room to cycle through all centralized background music sources connected to the PA-6000 series matrix amplifier and adjust room volume up and down with clear digital visual feedback.
Built-In Local Bluetooth Receiver
Equipped with a local wireless Bluetooth audio receiver directly on the wall plate, allowing users to pair their smartphone or laptop and stream localized playlists into their room.
Ultra-Long 999-Meter CAT6 Transmission Reach
Communicates high-fidelity audio and digital control commands over standard straight CAT6 network cabling up to an impressive 999 meters away from the central AV plant rack.
Direct 24V DC Bus Power from Host Amplifier
Draws operational 24V DC phantom bus power directly through the CAT6 cable from the central matrix amplifier, requiring zero local electrical wiring or external power bricks.
Local Line & Microphone Audio Inputs
Includes dedicated local 3.5mm line and microphone input sockets right on the faceplate, facilitating local presentations, speech events, or instrument hookups.
Supports Up to 6 Remote Panels per System
The PA-6000 series matrix architecture supports up to 6 individual PA-6000WP remote wall plates, providing one dedicated controller for each of the 6 output zones.
Clean Flush In-Wall Architectural Styling
Engineered with a sleek, low-profile faceplate (120.5 × 85 × 36.5 mm) designed for flush mounting into standard commercial electrical wall boxes.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | CMX PA-6000WP |
| Brand | CMX Audio |
| Product Type | In-Wall Commercial Audio Matrix Remote Control Wall Panel |
| Compatible Amplifiers | CMX PA-6000 Series Matrix Amplifiers (PA-6030MX / PA-6060MX / PA-6120MX / PA-6030MW / PA-6060MW / PA-6120MW) |
| Zone Capacity | 6 Discrete Output Zones |
| System Capacity | Up to 6 Remote Control Wall Panels per Matrix Amplifier (1 Unit per Zone) |
| Transmission Medium | Straight CAT6 Network Cable with RJ45 Connector |
| Maximum Control Distance | Up to 999 Meters |
| In-Room Wireless Audio | Built-In Local Bluetooth Audio Receiver for Room Playback |
| Local Audio Inputs | Line Input (200 mV, 15 kΩ) & Microphone Input (30 mV, 1 kΩ) |
| Front Panel Controls | Source Selection Buttons, Volume Level Up/Down Keys, Digital Display |
| Frequency Response | 20 Hz – 20 kHz |
| Total Harmonic Distortion (THD) | < 1% at RMS, 1 kHz |
| Signal-to-Noise Ratio (SNR) | > 70 dB |
| Power Supply | Direct 24V DC (±20%) Bus Power Supplied by Central Matrix Amplifier |
| Power Consumption | 3 Watts Maximum |
| Operating Temperature / Humidity | -20°C to +70°C | < 95% Non-Condensing |
| Mounting Configuration | In-Wall Flush Mounting (Standard Commercial Wall Box) |
| Dimensions (W × H × D) | 120.5 mm × 85 mm × 36.5 mm |
| Net Weight | 0.15 kg |
Frequently Asked Questions
Which amplifiers work with the CMX PA-6000WP remote panel?
The PA-6000WP is designed exclusively for the CMX PA-6000 series matrix mixer amplifiers (such as PA-6030MX, PA-6060MX, PA-6120MX, PA-6030MW, PA-6060MW, and PA-6120MW), transmitting digital control data and high-definition audio across CAT6 cabling.
How many PA-6000WP panels can be installed on one matrix amplifier?
A total of 6 remote wall panels can be connected to a single 6-zone matrix amplifier, providing one dedicated in-room remote controller for each of the six discrete audio zones.
Can users stream Bluetooth music directly to their individual room?
Yes. Each PA-6000WP wall panel incorporates its own localized Bluetooth audio receiver. When connected to a phone or tablet, that device’s audio streams exclusively through that specific room’s loudspeakers.
Does the wall plate need local 230V AC power or a local adapter?
No. The PA-6000WP receives 24V DC bus power directly through the CAT6 network cable from the central matrix amplifier, making installation clean and eliminating the need for local power outlets behind the wall.
What is the maximum cable distance from the central amplifier?
The PA-6000WP supports extreme cable runs up to 999 meters using standard straight CAT6 network cable, allowing placement in distant rooms across extensive hotel, resort, and commercial properties.
