Samsung VM55C-R 55″ Razor-Thin 0.88mm Bezel Commercial Video Wall Display (LH55VMCRBGBXXL)

Original price was: Rs.270,000.00.Current price is: Rs.226,600.00. Price Excluding TAX

Razor-Thin 0.88mm Bezel-to-Bezel: Features an ultra-slim 0.44mm even bezel that renders grid lines virtually invisible for continuous visual immersion.
500 Nit Anti-Glare Commercial IPS Panel: Delivers vibrant, reflection-free presentation and wide 178° viewing angles in challenging high-ambient-light spaces.
24/7 Mission-Critical Durability: Built for continuous, round-the-clock operation in mission-critical security operation centers, broadcast studios, and airports.
UHD Daisy Chain up to 5×5 Matrix: Stream Ultra HD 4K content seamlessly across multi-screen arrays via DisplayPort 1.2 without requiring external splitters.
Advanced Factory Calibration: Pre-tuned for exacting color balance, gamma curves, and brightness uniformity to deliver consistent panel-to-panel harmony.
Proprietary Picture Enhancement: Samsung’s digital image processor sharpens edge details, optimizes contrast, and reduces color banding for cinematic clarity.
Enterprise Control & Management: Features RS232C loop-through, RJ45 LAN control, IR receiver, and Samsung Knox-level remote device monitoring.
Ultra-Slim Profile & VESA Compliance: Streamlined industrial chassis with standard 600x400mm VESA pattern supports front-serviceable push-pull video wall mounts.

Categories: Digital Signage, Display & Monitor, Samsung, Video Wall

Description
Reviews 0

Product Overview

The Samsung VM55C-R (Model: LH55VMCRBGBXXL) sets the benchmark for ultra-premium commercial video walls. Engineered with a revolutionary 0.88 mm bezel-to-bezel (0.44 mm even bezel) design, the VM55C-R produces a practically seamless visual expanse that captivates audiences in corporate experience centers, high-security surveillance hubs, luxury retail flagships, and TV broadcast studios.

Boasting a high-output 500 nit non-glare IPS display, the VM55C-R distributes uniform brightness and true-to-life colors across an ultra-wide 178° viewing angle, ensuring flawless visual communication regardless of where observers stand. With built-in DisplayPort 1.2 and HDMI 2.0 daisy-chain capabilities, system integrators can deploy expansive UHD content across matrices up to 5×5 without external video processors. Rated for continuous 24/7 commercial duty cycles, the VM55C-R is designed to perform reliably under demanding commercial environments.

Key Technical Specifications

Display Diagonal	55 Inches (1.38 m)
Panel Technology	IPS Panel (Non-Glare, Anti-Reflective Coating)
Native Resolution	Full HD (1,920 × 1,080 pixels)
Brightness (Typical)	500 nits (cd/m²)
Contrast Ratio	1,000:1 (Dynamic Contrast: 100,000:1)
Bezel Width	0.88 mm B2B (0.44 mm Even Razor-Thin Bezel)
Viewing Angles (H/V)	178° / 178° Ultra-Wide
Operational Lifetime	24/7 Continuous Mission-Critical Commercial Grade
Connectivity – Inputs	2x HDMI 2.0 (HDCP 2.2), 1x DisplayPort 1.2, 1x DVI-D, 1x USB 2.0, 1x 3.5mm Stereo Audio In
Connectivity – Outputs	1x DisplayPort 1.2 (Video Loop Out), 1x 3.5mm Stereo Mini Jack Audio Out
External Control	RS232C In/Out (Stereo Jack), RJ45 (LAN) In, IR In
VESA Mounting Standard	600 × 400 mm
Frame Finish	Glossy Black Industrial Chassis
Power Requirements	AC 100-240V 50/60Hz Internal Power Supply

Commercial Audio Application & Installation Notes

Installing an ultra-narrow bezel display array such as the Samsung VM55C-R requires meticulous mechanical alignment and acoustic coordination:

Precision Push-Pull Pop-Out Mounting: Due to the razor-thin 0.44mm bezel edge, always utilize precision micro-adjustable pop-out video wall brackets (e.g., Saatvik VWS series or B-Tech pop-out mounts) to ensure perfect 8-axis alignment without panel edge stress.
Commercial Audio System Pairing: Route audio through dedicated DSP matrix switchers (such as Biamp, BSS, or Erthpot) connected to the master display loop-out. Deploy matched commercial soundbars or steerable column arrays (JBL, Tannoy, or RCF) calibrated with acoustic delay to eliminate lip-sync drift in large presentation spaces.
RS232 / IP Daisy-Chained Control: Daisy-chain RS232C cables across all monitors in serial order and assign unique Set IDs (1 to N) to enable unified power sequencing, input switching, and video wall layout adjustments via Crestron, Extron, or central AV control panels.
Power & Surge Sequencing: Deploy power distribution units (PDUs) with staggered inrush sequencing to prevent breaker trips during full-array simultaneous cold boot.
