CMX CS-4200 Professional 4-Channel Power Amplifier (4x200W)
Original price was: Rs.48,011.00.Rs.43,784.00Current price is: Rs.43,784.00. Price Excluding TAX
► Four Independent Discrete Amplifier Channels
► High-Efficiency 85% Class-D Digital Topology
► 4×200W at 8Ω / 4×350W at 4Ω Output
► Dual Bridge Mode up to 2×600W
► Balanced XLR Inputs & Speakon Outputs
► Complete Protection Suite (Clip, Overload, Thermal)
► Compact 19-Inch 1U Rack-Mount Chassis
CMX CS-4200 Professional 4-Channel Power Amplifier (4x200W)
High-Efficiency 4-Channel Class-D Rack-Mount Power Amplifier for Commercial AV & Fixed Installation
The CMX CS-4200 is a professional 4-channel rack-mount power amplifier engineered for multi-zone commercial sound systems, auditoriums, entertainment venues, and houses of worship. Utilizing high-efficiency 85% Class-D digital topology, it delivers a rated output of 4×200W at 8Ω (4×350W at 4Ω) and up to 2×600W in bridge mode — providing four discrete amplifier channels in a compact 19-inch 1U chassis.
Core Engineering Features
Four Discrete Amplifier Channels
Combines four independent power amplifier modules into a single 1U enclosure, allowing audio integrators to power multiple distributed speaker zones or bi-amp multi-way speaker systems while conserving valuable rack real estate.
High-Efficiency 85% Class-D Circuitry
Advanced digital switching power supply topology delivers up to 85% electrical efficiency, substantially reducing thermal heat buildup and eliminating the need for noisy, bulky heatsinks in demanding continuous installations.
Flexible Stereo / Parallel / Bridge Modes
Independent output mode switches allow flexible channel pairing into 4-channel stereo, parallel distribution, or 2-channel bridged operation producing up to 2×600W into 4Ω for driving subwoofers.
Professional XLR & Speakon I/O
Equipped with balanced XLR male input connectors for interference-free long cable runs and industry-standard Speakon latch-lock output terminals ensuring secure, reliable speaker connectivity.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | CS-4200 |
| Amplifier Type | 4-Channel Professional Class-D Power Amplifier |
| Amplifier Topology | High-Efficiency Digital Switching Class-D |
| Amplifier Efficiency | Up to 85% |
| Rated Output Power (8Ω Stereo) | 4 × 200W |
| Rated Output Power (4Ω Stereo) | 4 × 350W |
| Bridge Output Power (8Ω) | 2 × 330W |
| Bridge Output Power (4Ω) | 2 × 600W |
| Frequency Response | 20 Hz – 20,000 Hz (±0.5 dB) |
| Total Harmonic Distortion (THD) | < 0.3% |
| Signal-to-Noise Ratio (S/N) | > 105 dB |
| Channel Crosstalk | > 75 dB |
| Input Impedance | 20 kΩ (Balanced) / 10 kΩ (Unbalanced) |
| Input Sensitivity & Connector | 1V Sensitivity | 4 × Balanced XLR Male Connectors |
| Output Connectors | 4 × Speakon Female Latch-Lock Connectors |
| Protection Circuits | Clip Limiting, High Temperature Shutdown, Overload & Short-Circuit Protection |
| Power Supply | AC 100 – 240V, 50/60 Hz Universal AC Input |
| Dimensions (W × D × H) | 484 × 375 × 44 mm (Standard 19″ 1U Rack) |
| Net Weight | 5.0 kg |
Frequently Asked Questions
What is the rated power output of the CMX CS-4200?
The CMX CS-4200 delivers 4×200W continuous RMS at 8Ω per channel in stereo mode, 4×350W at 4Ω stereo, and up to 2×600W into 4Ω in dual bridge mode, providing flexible power distribution from a single 1U unit.
Can the CS-4200 channels be bridged for subwoofers?
Yes. Channels 1/2 and channels 3/4 can each be independently switched into bridge mode, delivering up to 2×600W into 4Ω or 2×330W into 8Ω — perfect for powering subwoofers alongside mid-high satellite speakers.
What type of audio inputs and speaker outputs does it feature?
The CS-4200 provides 4× balanced XLR male inputs (20kΩ balanced / 10kΩ unbalanced) for professional low-noise signal feed, and 4× robust Speakon female latch-lock output terminals for secure speaker cabling.
What protection features are included in the amplifier?
The unit features a comprehensive protection suite including clip limiting, thermal overload detection with high-temperature auto-shutdown, output overload protection, and short-circuit protection on all four channels.
What is the physical size and rack footprint of the CS-4200?
The CS-4200 occupies standard 19-inch 1U rack dimensions (484 mm W × 375 mm D × 44 mm H) and weighs 5.0 kg, making it lightweight and compact for rack integration.
Engineer Your Perfect Commercial Audio & Visual Environment
Contact our AV specialists for professional product selection, system integration, and turnkey installation support.
